DIO60010

描述

The DIO60010 is a high-efficiency synchronous step-down DC-DC regulator. The DIO60010 can achieve up to 1 A continuous output current from a 2.5 V to 5.5 V input voltage with excellent load and line regulation. The output voltage can be regulated to as low as 0.6 V. Constant-on-time(COT) control provides a fast transient response and eases loop stabilization. The DIO60010 includes an automatically entered power save mode to maintain high efficiency down to very light loads for extending the system battery run-time. The device features a Power-good signal. The DIO60010 is ideal for a wide range of applications, including portable navigation devices, set top boxes and media players.
